Commissioning Waste Management Agricultural Residue Floating Drum Scrubber-Integrated Biogas Plant

Commissioning Waste Management Agricultural Residue Floating Drum Scrubber-Integrated Biogas Plant Specification

Type
Biogas Plant

Material
SS304

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Drive Type
Electric

Voltage
440 Volt (v)

Power
250000 Watt (w)

Commissioning Waste Management Agricultural Residue Floating Drum Scrubber-Integrated Biogas Plant Trade Information

Minimum Order Quantity
1 Number

Delivery Time
4

About Commissioning Waste Management Agricultural Residue Floating Drum Scrubber-Integrated Biogas Plant

This anaerobic digestion facility processes agricultural residues and organic waste streams via a semi-continuous, high-rate digestion process.

* **Digester Flow Dynamics & Gas Containment:** The digester operates under a plug-flow regime transitioning into a continuous stirred-tank reactor (CSTR) configuration. Biogas accumulates beneath a balanced, water-sealed floating drum that telescopes vertically along a central guide shaft, ensuring steady isobaric gas delivery while accommodating volumetric fluctuations during peak digestion phases.

* **Mechanical Feeding & Agitation:** Agricultural biomass undergoes automated shredding and maceration before an industrial progressive cavity feed pump introduces slurry into the lower digestion zone. Intermittent agitation via slow-speed, high-torque dual-paddle vertical mixers prevents crust stratification, disperses scum, and eliminates dead zones to optimize microbial-substrate contact.

* **Thermal Regime:** The vessel maintains a strictly regulated mesophilic envelope (37C 1C) using an internal stainless-steel hot-water circulation jacket/internal coil grid linked to a closed-loop hydronic heating system with automated PLC-driven thermostatic valves.

* **Gas Treatment & Energy Recovery:** Raw biogas is routed through an integrated counter-current packed-bed chemical scrubber to strip $\text{H}_2\text{S}$ and trace $\text{CO}_2$, yielding purified biomethane. Upgraded fuel powers a combined heat and power (CHP) engine for electrical generation and parasitic digester heating, with overflow digestate separated into nutrient-dense bio-fertilizer.
