New Pharmaceutical 0.1Torr Three Stage High Performance Booster Pump

New Pharmaceutical 0.1Torr Three Stage High Performance Booster Pump Specification

Flow Rate
120-150 m3/h

Speed
2900 RPM

Voltage
380V/3 Phase/50Hz

Features
High Efficiency, Corrosion Resistant, Low Noise

Control System
PLC Compatible

Inlet/Outlet
DN50 / DN50

Head Size
Customizable

Mounting Type
Base Mounted

Discharge Pressure
Up to 0.1 Torr

Fuel Tank Capacity
N/A (Electric Driven)

Noise Level
75 dB

Frequency
50 Hz

Caliber
DN50

Working Temperature
5C to 40C

Max Suction
0.1 Torr

Theory
Three Stage Booster, Three Stage Booster Pump

Material
Cast Iron / Stainless Steel

Structure
Horizontal Split, Horizontal Multistage

Power
7.5 kW, 2.2 kW

Standard
ISO/CE Certified

Fuel Type
Electric, Electric

Pressure
High Pressure, 0.1 Torr

Usage
Pharmaceutical, Pharmaceutical Processing

Application
Pharmaceutical, Chemical Processing, Vacuum Systems, Pharmaceutical, Chemical, Laboratory Vacuum Boosting

Suction Type
High Vacuum

Seals Type
Oil Sealed

Priming
Automatic

Pump Type
Booster Pump, Vacuum Booster Pump

Capacity
120-150 m3/h

Weight
105 kg

Pump Body Coating
Anti-corrosive epoxy

Vacuum Connection
KF flange

Motor Brand
Siemens / ABB (option)

Service Life
>20,000 hours

Max. Allowable Particle Size
50 micron

Leak Rate
1x105 Pam3/s

Cooling Method
Air cooled

Protection Class
IP55

New Pharmaceutical 0.1Torr Three Stage High Performance Booster Pump Trade Information

Minimum Order Quantity
1 Unit

Main Domestic Market
Gujarat

About New Pharmaceutical 0.1Torr Three Stage High Performance Booster Pump

Introducing the new pharmaceutical-grade booster pump, engineered for unparalleled performance in demanding vacuum applications. This innovative three-stage pump achieves an impressive ultimate vacuum of 0.1 Torr, making it ideal for sensitive pharmaceutical processes requiring deep and stable vacuum levels. Its high-performance design ensures rapid evacuation and efficient operation, significantly reducing processing times and enhancing productivity. Built with the stringent requirements of the pharmaceutical industry in mind, this booster pump offers exceptional reliability, precision, and cleanliness, safeguarding product integrity. Experience superior vacuum technology tailored for your critical pharmaceutical manufacturing needs.

Optimized for Pharmaceutical Processes

This booster pump is tailored to the stringent demands of pharmaceutical and chemical processing, providing high vacuum performance for precise applications. Its anti-corrosive coating and ability to handle up to 50-micron particles ensure clean and reliable operation. Its ISO/CE certification and customizable head size allow seamless integration into new or existing systems, enhancing workflow efficiency and processing reliability for pharmaceutical and laboratory settings.

Durability and Efficiency Assured

Built from cast iron or stainless steel, this pump supports a long operational life of over 20,000 hours. The Siemens/ABB motor options, coupled with oil-sealed technology and PLC compatibility, offer exceptional energy efficiency and reduced maintenance requirements. Air-cooled operation, low noise emission (75 dB), and robust leak protection (IP55) make it an ideal solution for environments demanding high performance and reliability.

FAQ's of New Pharmaceutical 0.1Torr Three Stage High Performance Booster Pump:

Q: How does the three-stage design benefit pharmaceutical vacuum applications?

A: The three-stage booster mechanism provides exceptionally high vacuum levels (down to 0.1 Torr), ensuring precise control and enhanced throughput required in pharmaceutical and chemical processing. This multi-stage design also improves energy efficiency and maintains performance stability during continuous operations.

Q: What is the recommended maintenance process for this booster pump?

A: Routine maintenance mainly involves monitoring the oil seal condition, checking for leaks, and ensuring adequate airflow for the air-cooled system. Regular inspections help extend its lifespan beyond 20,000 hours and maintain optimal performance in pharmaceutical and laboratory settings.

Q: Where can this booster pump be installed and what mounting options are available?

A: The pump is designed for base-mounted installations in controlled environments such as pharmaceutical plants, chemical processing units, and laboratories. Its horizontal, split-structure configuration allows easy integration into both new and existing vacuum systems.

Q: When should I consider customizing the head size or material of the pump?

A: Customization is advisable when specific process requirements necessitate a unique head size, material compatibility, or integration with non-standard piping. Cast iron or stainless steel options and customizable DN50 connections ensure compatibility with diverse operating environments.

Q: What are the benefits of using an anti-corrosive epoxy coating on the pump body?

A: The anti-corrosive epoxy coating protects the pump from harsh chemicals and moisture, enhances its durability, and enables reliable operation in demanding pharmaceutical and chemical processing environments.

Q: How is the pump controlled and can it be integrated with modern systems?

A: The pump is PLC compatible, allowing it to be connected with automated control systems for real-time monitoring, process automation, and optimal performance management within industrial setups.
