New Petrochemical 1Torr Pilot Electrical Vacuum System

New Petrochemical 1Torr Pilot Electrical Vacuum System Specification

Discharge Pressure
Up to 1 bar

Flow Rate
Up to 30 m3/h

Inlet/Outlet
DN40 / DN25

Control System
Automatic PLC Control

Max Suction
1 Torr (1.333 mbar)

Fuel Tank Capacity
N/A (Electric Drive)

Working Temperature
-5C to 80C

Speed
Up to 1450 rpm

Frequency
50Hz

Mounting Type
Floor Mounted

Voltage
380V / 50Hz

Theory
Rotary Vane Vacuum Pump, Vacuum Pump System

Caliber
Standard Industrial

Noise Level
<68 dB(A)

Features
Corrosion-resistant, Energy-efficient, Overload Protection

Head Size
Customizable

Material
Stainless Steel 304 / 316

Structure
Skid-mounted Modular System, Compact Skid Mounted

Power
3.5 kW, 1.5 kW - 7.5 kW

Standard
ISO 9001:2015

Fuel Type
Electric, Electric

Pressure
Low Pressure (Vacuum), 1 Torr (Max Vacuum)

Usage
Petrochemical Pilot Systems, Petrochemical Pilot System, Laboratory Use

Application
Laboratory, Pilot Plant Testing, Vacuum extraction, Solvent recovery, Chemical distillation

Suction Type
Positive Displacement

Seals Type
Mechanical Seal

Priming
Self-priming

Pump Type
Rotary Vane, Rotary Vane / Roots / Liquid Ring

Capacity
1 Torr vacuum capability

Vacuum Gauge
Digital/Analog Display Included

Service Life
20,000 Operating Hours

Protection Level
IP55 Motor Protection

Dimensions
1200mm 600mm 900mm (LWH)

Safety
Built-in Overload and Overheat Protection

Insulation Class
Class F

Cooling System
Air/Water Cooled Options

Weight
Approx. 150 - 300 kg

Ambient Humidity
90% RH

Phase
Single or Three Phase

Maintenance
Low, Easy Access for Overhaul

New Petrochemical 1Torr Pilot Electrical Vacuum System Trade Information

Minimum Order Quantity
1 Unit

Main Domestic Market
Gujarat

About New Petrochemical 1Torr Pilot Electrical Vacuum System

This new petrochemical pilot electrical vacuum system is engineered for precision and efficiency, achieving a deep vacuum of 1 Torr. Designed specifically for the petrochemical industry, it facilitates critical pilot-scale operations, enabling researchers and engineers to test and optimize processes with high accuracy. The system's electrical power source ensures reliable and consistent performance, making it ideal for sensitive applications where maintaining a stable vacuum environment is paramount. Its compact design and advanced controls offer a versatile solution for various experimental setups, contributing to safer and more effective development of new petrochemical products and processes.

Versatile Industrial Applications

Engineered for flexibility, the 1Torr Pilot Electrical Vacuum System is suitable for petrochemical pilot systems, laboratory testing, vacuum extraction, and solvent recovery. Its compatibility with rotary vane, roots, and liquid ring pump types meets diverse operational needs, while customizable head sizes and stainless-steel construction ensure chemical resistance for a wide range of process media.

Advanced Control and Safety

The system incorporates automatic PLC control and built-in overload and overheat protection, supporting safe, consistent operation. Real-time vacuum status is available via digital and analog displays, and motor insulation class F with IP55 protection ensures long-term durability in demanding environments. Quick access for overhaul and low overall maintenance requirements keep downtime to a minimum.

FAQ's of New Petrochemical 1Torr Pilot Electrical Vacuum System:

Q: How is the New Petrochemical 1Torr Pilot Electrical Vacuum System maintained?

A: This vacuum system is designed for low maintenance, featuring easy access for overhauls and routine servicing. The modular skid-mounted structure and corrosion-resistant stainless-steel materials simplify inspection and part replacement, minimizing operational downtime.

Q: What types of environments and processes is this vacuum system suitable for?

A: It excels in laboratory environments, petrochemical pilot plant setups, vacuum extraction, solvent recovery, and chemical distillation. Its robust protection (IP55), ability to withstand ambient humidity up to 90% RH, and a working temperature range of -5C to 80C make it suitable for challenging industrial settings.

Q: When should I consider choosing air-cooled versus water-cooled options?

A: Air-cooled systems are recommended for installations where water supply is limited or simplicity of setup is preferred, while water-cooled models are optimal for high-ambient temperature environments or continuous heavy-duty operation, promoting better thermal management.

Q: Where can this vacuum system be installed?

A: The compact, skid-mounted design allows floor mounting in laboratories, pilot plants, and industrial test facilities. Its modular structure facilitates integration into existing process lines or as a standalone vacuum solution.

Q: What are the primary benefits of the built-in PLC control system?

A: The automatic PLC control system enhances reliability and operational efficiency by automating system processes, monitoring vacuum and performance parameters, and offering easy interface for adjustments and real-time diagnostics.

Q: How does the overload and overheat protection work?

A: Safety is assured through advanced sensors that monitor motor load and temperature. If abnormal conditions are detected, the system automatically shuts down to prevent equipment damage, protecting both the vacuum system and connected processes.
