Service Wood SS316 Pilot Efficiency Self Cleaning Screw Press

Service Wood SS316 Pilot Efficiency Self Cleaning Screw Press Specification

Recycle Rate
Up to 90%

Noise Level
<75 dB

Frequency
50 Hz

Flow Rate
200-1500 LPH

Pump Type
Integrated progressive cavity pump

Ph Level
6.5-8.5

Efficiency (%)
Above 90%

Power Consumption
2-7 kW (varies with model)

Water in conductivity
Varies by feed, up to 2000 S/cm

Water Out Conductivity
50 S/cm

Technology
Pilot Efficiency Self Cleaning Screw Press

Feature
Self-cleaning, High-efficiency, Compact design

Usage & Applications
Sludge dewatering, Industrial ETP, STP, Brewery waste, Paper industry, Food processing, Dye & textile units

Power Source
Electric

Water Source
Industrial and municipal wastewater

Automatic Grade
Semi-Automatic

Purity Level
Up to 98%

Product Type
Self-Cleaning Screw Press

Material
SS316 Stainless Steel

Drive Type
Electric Motor Driven

Voltage
415 V AC

Volume
Pilot-scale / Customizable

Filter Type
Sieve Drum/Inbuilt Mesh

Capacity
200-1500 LPH (Liters per Hour)

Installation Type
Skid Mounted

Dewatering Performance
High solid capture with minimal water content in cake

Discharge Type
Automatic cake discharge

Control Panel
Digital PLC-based control

Mobility
Optional trolley for easy movement

Cleaning Mechanism
Continuous self-cleaning with internal brush mechanism

Inlet Solids Concentration
0.5-5% TS possible

Frame Construction
Heavy-duty corrosion-resistant frame

Protection Grade
IP55 electrical protection

Service Wood SS316 Pilot Efficiency Self Cleaning Screw Press Trade Information

Minimum Order Quantity
1 Number

Delivery Time
4

About Service Wood SS316 Pilot Efficiency Self Cleaning Screw Press

The Whirler Service Wood SS316 Pilot Efficiency Self-Cleaning Screw Press is a specialized dewatering solution designed for high-performance testing and small-batch processing in the wood and pulp industries. Engineered with superior SS316 stainless steel, this unit offers exceptional corrosion resistance and longevity, even when handling aggressive organic acids or specialized chemical treatments.

As a pilot-scale machine, it provides a crucial platform for R&D, allowing for precise process optimization and data collection before full-scale industrial deployment. The "Efficiency" designation highlights its optimized screw geometry and drive system, which maximize liquid-solid separation while minimizing energy consumption. A key feature is the advanced self-cleaning mechanism; by continuously clearing the filter screen during operation, it prevents blinding and ensures consistent throughput without manual cleaning intervals. This fully automated, low-maintenance system delivers a high-dryness cake and clear filtrate, making it an indispensable tool for sustainable waste management and resource recovery in modern wood-processing facilities.

Efficient Dewatering Performance

Maximize solid capture and reduce water content in your sludge cake with the Service Wood SS316 Screw Press. Its advanced self-cleaning mechanism and integrated mesh filtration allow continuous and reliable operation, handling solids concentrations from 0.5% to 5% total solids. Achieve above 90% efficiency and up to 98% purity level, delivering unmatched results in industrial and municipal wastewater treatment.

Robust, Corrosion-Resistant Construction

Crafted from SS316 stainless steel, the screw press provides exceptional corrosion resistance and durability, perfectly suited for challenging environments. The heavy-duty frame and IP55 electrical protection ensure long-term reliability, even in continuous use. This skid-mounted or customizable unit offers mobility options for flexible positioning in various installations.

Smart Automated Controls and User-Friendly Features

Operate with ease using the digital PLC-based control panel, which automates and monitors critical system functions. The screw press features automatic cake discharge, integrated progressive cavity pumps, and optional trolley mobility. With a low power consumption (2-7 kW) and less than 75 dB noise level, it ensures operational efficiency and minimal disruption.

FAQ's of Service Wood SS316 Pilot Efficiency Self Cleaning Screw Press:

Q: How does the SS316 Pilot Efficiency Self Cleaning Screw Press achieve high dewatering efficiency?

A: The screw press employs a continuous self-cleaning mechanism with an internal brush and sieve drum, allowing sustained high solid capture. This design ensures efficient dewatering by minimizing water content in the discharge cake, with an efficiency rate above 90% and purity levels up to 98%.

Q: What is the recommended application for this screw press?

A: This unit is suitable for sludge dewatering in industrial and municipal wastewater plants (ETP and STP), as well as brewery waste, paper manufacturing, food processing, dye and textile industries, and other processes that require high-efficiency solid-liquid separation.

Q: When should the screw press be installed, and how is it set up?

A: Installation is straightforward and typically performed wherever sludge dewatering is required, either as a stand-alone skid-mounted unit or integrated into existing treatment lines. The mobile trolley option adds flexibility, allowing placement and repositioning according to operational needs.

Q: Where can the screw press operate based on environmental conditions?

A: Constructed from SS316 stainless steel with IP55 electrical protection, it is designed to withstand corrosive and wet environments typical of industrial and municipal wastewater treatment facilities.

Q: What does the self-cleaning process involve, and how does it benefit users?

A: The internal brush mechanism continuously cleans the internal mesh and sieve, preventing clogging. This design maintains consistent throughput, minimizes manual maintenance, and extends service life, delivering reliable and uninterrupted operation.

Q: How is the system controlled and monitored during operation?

A: All major functions, including cake discharge and dewatering process parameters, are managed through a digital PLC-based control panel. Integrated safety and monitoring features optimize performance and provide easy operational oversight.

Q: What are the operational advantages of the screw press?

A: Key benefits include high efficiency, reduced downtime due to self-cleaning, compact design, low energy consumption, adaptability for various flow rates (200-1500 LPH), and compliance with industry needs for purity and environmental standards.
