New Gas SS316L STP Efficient ETP Screw Press

New Gas SS316L STP Efficient ETP Screw Press Specification

Flow Rate
1-5 m3/h

Efficiency (%)
>95%

Power Consumption
2-7 kW

Water in conductivity
2000 S/cm

Water Out Conductivity
<500 S/cm

Ph Level
6.5-8.5

Recycle Rate
80-90%

Frequency
50 Hz/60 Hz

Technology
Screw Press Dewatering

Feature
Efficient sludge dewatering, corrosion-resistant

Usage & Applications
ETP, STP, Industrial & Municipal Wastewater Treatment

Noise Level
<75 dB

Pump Type
Submersible/Feed pump compatible

Material
SS316L

Power Source
Electric

Drive Type
Screw

Product Type
ETP Screw Press

Volume
Up to 5000 L/h

Purity Level
High

Water Source
Municipal, Industrial

Voltage
380V/415V

Automatic Grade
Automatic

Filter Type
Screw Press Filtration

Capacity
Depends on model, up to 5 m3/h

Installation Type
Skid Mounted

Design Life
>10 years

Inlet Pressure
0.1-0.3 MPa

Sludge Cake Moisture Content
75%

Control Panel
PLC based touch screen

Weight
~850 kg (varies with model)

Cleaning System
Automatic self-cleaning system

Safety Features
Overload protection, emergency stop

Operating Temperature
5-45C

Maximum Solids Concentration Input
35,000 mg/L

Dimensions (LxWxH)
Depends on capacity, typically: 2100x1100x1550 mm

Discharge Method
Screw press cake discharge

Solids Capture Rate
>90%

New Gas SS316L STP Efficient ETP Screw Press Trade Information

Minimum Order Quantity
1 Number

Delivery Time
4

About New Gas SS316L STP Efficient ETP Screw Press

The New Gas SS316L STP Efficient ETP Screw Press is a high-performance dewatering system specifically engineered for the rigorous demands of the gas industry and municipal water treatment. Constructed from premium SS316L stainless steel, this unit offers exceptional corrosion resistance and durability, ensuring long-term reliability even when handling aggressive chemical effluents or saline wastewater.

At its core, the screw press utilizes advanced multi-disc technology to create a self-cleaning, clog-free mechanism. This "Efficient" design prioritizes low energy consumption and minimal water usage while delivering superior solid-liquid separation. The fully automated system allows for continuous 24/7 operation with minimal manual intervention, significantly reducing operational labor and sludge disposal costs. By consistently producing high cake dryness and clear filtrate, it helps facilities meet stringent environmental standards. The New Gas SS316L Screw Press represents a sustainable and cost-effective solution for modern Sewage Treatment Plants (STP) and Effluent Treatment Plants (ETP) seeking operational excellence.

Superior Dewatering Efficiency

Engineered for maximum performance, the SS316L Screw Press delivers impressive solid concentration inputs up to 35,000 mg/L and maintains a solid capture rate above 90%. Its advanced screw press filtration and automatic self-cleaning system ensure a low maintenance, high-output operation, consistently achieving sludge cake moisture content around 75%.

User-Friendly Automation and Safety

Featuring a PLC-based touchscreen control panel, the system allows simple and intuitive operation. Safety is paramount, with integrated overload protection and an emergency stop function. Designed for user convenience and long-term reliability, the press guarantees a service life exceeding 10 years, minimizing downtime and maximizing productivity.

FAQ's of New Gas SS316L STP Efficient ETP Screw Press:

Q: How does the SS316L Screw Press improve sludge dewatering efficiency?

A: The SS316L Screw Press utilizes advanced screw press dewatering technology to achieve high solid capture rates (>90%) and reduces sludge cake moisture to 75%. Its automatic self-cleaning system and efficient solid-liquid separation provide consistent, reliable performance in various wastewater treatment settings.

Q: What types of wastewater treatment applications can this system be used for?

A: This screw press is suitable for a wide range of applications, including Effluent Treatment Plants (ETP), Sewage Treatment Plants (STP), and both municipal and industrial wastewater management. Its design accommodates varying flow rates and can handle input concentrations up to 35,000 mg/L.

Q: When should the automatic self-cleaning function be activated?

A: The automatic self-cleaning system operates periodically during processing to prevent clogging, maintain optimal performance, and reduce manual maintenance. The frequency and duration can be adjusted through the PLC touchscreen interface based on site requirements.

Q: Where can this screw press be installed?

A: With its skid-mounted construction and compact design, the SS316L Screw Press can be installed in various locations, from municipal wastewater plants to industrial facilities. Its footprint and dimensions adapt to system capacity, making it suitable for both retrofit and new installations.

Q: What are the benefits of using SS316L material in this system?

A: SS316L stainless steel is highly resistant to corrosion and chemical attack, ensuring longevity and minimal maintenance in harsh wastewater environments. This material guarantees durability and helps maintain high levels of purity and hygiene in treated water.

Q: How is the screw press operated and monitored?

A: Operation and monitoring are managed through a PLC-based touch screen control panel, allowing operators to adjust parameters, monitor performance, and initiate cleaning or safety functions with ease. This automation simplifies operation and enhances process control.

Q: What process advantages does the skid-mounted screw press offer?

A: The skid-mounted design allows for rapid deployment, easy integration into existing systems, and straightforward relocation if needed. Combined with plug-and-play installation and compatibility with submersible or feed pumps, it offers unmatched flexibility for end users.
