Trial CETP Automatic used decanter

Trial CETP Automatic used decanter Specification

Product Type
Automatic Decanter Centrifuge for CETP

Material
Stainless Steel Body, Mild Steel Parts

Type
Horizontal Cylindrical Decanter Centrifuge

Centrifugal Compressor
Not Included-Machine Uses Rotating Drum

Centrifugal Chamber
Stainless Steel Shell, Horizontal Axis

Motor
Three Phase Electric Motor, Approx. 15-30 HP

Temperature Control Range
Ambient Temperature Operation

Speed
Approx. 3200 RPM

Drum Diameter
Approx. 300-400 mm (Estimated)

Installation Type
Fixed, Skid/Frame Mounted

Control Panel
PLC Based Automatic Control

Maintenance
Low, Easy Access Panels

Application
Effluent Treatment, Sludge Dewatering, CETP, Wastewater Treatment Plants

Power Supply
415V, 50Hz, Three Phase

Residue Discharge
Continuous or Batch Discharge Option

Drum Material
SS304/SS316 (Depending on Model)

Operation
Fully Automatic with Continuous Discharge

Drive Type
Belt/Pulley Drive

Used Condition
Pre-owned, Inspected for Operation

Feed Capacity
Approximately 5-10 m3/hr, application dependent

Trial CETP Automatic used decanter Trade Information

Minimum Order Quantity
1 Number

Delivery Time
4

Trial CETP Automatic used decanter About

This repair project involved the comprehensive refurbishment of a used automatic decanter centrifuge deployed for trial operations at a Common Effluent Treatment Plant (CETP). Given the abrasive nature of CETP sludge, the centrifuge underwent complete dismantling and deep chemical cleaning.

The repair and servicing scope included:

* **Conveyor scroll restoration**: Rebuilding worn flights and applying high-grade tungsten carbide hardfacing for enhanced wear protection.

* **Bearing and seal replacement**: Installing new main bearings, conveyor bearings, lip seals, and O-rings to ensure leak-free operation.

* **Gearbox overhaul**: Servicing the planetary gearbox and updating automatic control sensors.

* **Precision dynamic balancing**: Balancing both the bowl and scroll assemblies individually and together to minimize operational vibration and noise.

Following reassembly, the decanter underwent rigorous trial testing to calibrate the automatic feed and differential speed systems. The repair successfully restored optimal dewatering efficiency, ensuring stable solids separation for the CETP trial.

Optimized Sludge Dewatering

Achieve superior solid-liquid separation efficiently with the fully automatic, continuous discharge decanter. Suitable for CETP and various wastewater applications, it operates at around 3200 RPM to ensure expedited sludge processing. The robust stainless steel drum promises longevity and resistance to corrosion, handling demanding effluent streams seamlessly.

User-Friendly Operation and Control

This decanter comes equipped with a PLC-based automatic control panel, enabling smooth, uninterrupted operation. Maintenance is simplified with easy-access panels, and the skid or frame-mounted design allows for fixed installation. The 415V, 50Hz, three-phase motor (approx. 15-30 HP) ensures reliable power and consistent performance.

FAQ's of Trial CETP Automatic used decanter:

Q: How is the Trial CETP Automatic Used Decanter installed and operated?

A: The decanter is designed for fixed, skid or frame-mounted installation. It is fully automatic, controlled via a PLC panel, and operates continuously once set up, requiring minimal manual intervention.

Q: What benefits does using this decanter bring to effluent or sludge treatment processes?

A: This machine offers efficient separation of solids and liquids, reduces manual sludge handling, and improves the quality of treated effluent. Its robust build and automatic operation lower maintenance needs and downtime.

Q: When should I choose a used decanter like this for my facility?

A: Consider this decanter when you need a reliable, cost-effective solution for treating moderate volumes of sludge or effluent (5-10 m3/hr) and seek reduced capital investment compared to new equipment, with assured performance through pre-inspection.

Q: Where can this automatic decanter centrifuge be effectively used?

A: It is suitable for common effluent treatment plants (CETP), municipal wastewater facilities, and industrial setups that require efficient sludge dewatering and liquid-solid separation.

Q: What is the typical process flow when using this decanter centrifuge?

A: Effluent or sludge is continuously fed into the rotating drum, where centrifugal force separates solids from liquids. The decanter can operate with either continuous or batch residue discharge, depending on your application requirements.

Q: How does the decanter ensure easy maintenance and accessibility?

A: With easy-access panels and a design focused on low maintenance, routine inspections or servicing can be performed swiftly-minimizing downtime and ensuring sustained operation.

Q: What materials are used in the construction of this decanter, and how does it affect durability?

A: Primary components, including the drum and centrifugal chamber, are made of corrosion-resistant stainless steel (SS304/SS316), and the supporting frame uses mild steel, offering both strength and durability for demanding environments.
